1200°C Opening multizone Compact lamps furnace

1200°C Opening multizone Compact lamps furnace

Discover our  1200°C Opening multizone Compact lamps furnace. Our engineering expertise in heating, atmosphere management, vacuum management, mechanical transfers, automation and regulation enables us to provide you with a solution that is perfectly adapted to your needs.
We adapt to your expectations by providing you with numerous solutions for research laboratories or industrial production.

All our equipment is CE compliant and is manufactured with materials that comply with current legislation.





Caractéristiques
Options
Caractéristiques (Fr) Specifications (Eng)

Atmosphère de travail

Process

Air

Air

Application

Application

Traction, fatigue

Traction, fatigue

Openable

Type of furnace

 Oui

Yes

Type d’éprouvette

Type of specimen

Petite éprouvette
Small specimen

Températures Maximales

Maximum temperatures

Jusqu’à 1200°C

Up to 1200°C

Capacité

Sizing

Sur consultation

Upon request

Caractéristiques (Fr) Specifications (Eng)

Hauteur chauffante
Heating height

Multiprogramme + enregistreur

Multiprogram + recorder

Examples



Opening multizone Compact lamps furnace 1200°C





Dimensions hors tout (L x H x prof mm)

Overall dimensions (W x H x deep mm)

170 x 95 x 260 mm 170 x 95 x 260 mm
Hauteur chauffante

Heating height

75mm 75mm
Zones de chauffe

Heating zones

4 4
Température maximale

Maximum temperature

1200°C 1200°C
Vitesse montée maximale

Temperature rising speed

20°C/s sur éprouvette plate ep.max 10mm largeur 20mm 20°C/s on flat specimen thk.max 10mm width 20mm
Vitesse refroidissement

Temperature cooling speed

20°c/sec (> 450°) 20°c/sec (> 450°)
Homogénéité thermique

Thermal homogeneity

< 1% sur zone utile < 1% on useful area
Eprouvette

Specimen

Plate ou cylindrique Flat or cylindrical
Tension alimentation

Voltage supply

240V mono. 240V mono.
Trous de passage pour l’ensemble de la ligne d’amarrage Passage holes for the entire mooring line
Possibilité de monter 2 extensomètres en opposition;  hauteur maxi passages jauges : 25mm Possibility of adding 2  opposite extensometers ; maximum height of gauge passages: 25mm
